運輸設備
|
安全耐用,昱辰保障 昱辰工業掌握鍛造/鑄造之整合能力,提供品質穩定的產品,進而受到國內外相關拖車零件產業的客戶信賴,我們提供多種拖車零件產品,包括:拖車球(Tow ball)、拖車座(Pintle Hooks)、拖車銷(Receiver Pin and Locks)、安全鏈條鎖座(Safety Chain Holders)、拖車桿(Receiver Bars)、拖車轉接器(Couplings)、拖車座轉換器(Receiver Bars)、軸組件(Drop Axle Assembly)等各類拖車用零件,委託我們來為這些拖車產品作生產及品質把關。 昱辰工業秉持著系統性的管理、設計、製造與品質控管,並符合各國拖車零件相關產品的規範,再加上公司自有的產品測試中心,更可為安全性要求極高的拖車產品注入一劑強心針,提供高品質的產品。 |
ABOUT YUH CHERN
LEAVE THE MOST IMPORTANT SCHEDULE
FOR YOUR TRUSTWORTHY PARTNER.
In 1979, Yuh Chern Manufacturing Co., Ltd. was established in Taichung City, Taiwan.
CORE BUSINESS
Since our inception, we have developed a professional hot forging manufacturing service model together with experienced stamping and machining competitiveness that focuses on standardized and customized products in the field of conveyor chains, trailer parts and related products.
THE ENDLESS PURSUIT FOR PERFECTION
Along with business growth, we had not only upgraded manufacturing facilities but also implemented the following management systems:
- ISO 9001 (Quality Management)
- ERP (Enterprise Resource Planning)
- SFT (Shop Floor Tracking)
- PLM (Product Lifecycle Management)
- APS (Advanced Planning and Scheduling)
EXPERIENCE MAKES THE DIFFERENCE
Over the decades, our research and development team has accumulated valuable expertise in product development in order to provide customers with professional technical advice in the early stages of their product development. The efforts include material analysis, structure design and surface treatment. By utilizing software such as AutoCAD, Solidworks, Autodesk Inventor, SolidCAM, Cimatron CAD/CAM and Geomagic Design, we are capable of processing more than a hundred development cases per year. This has allowed us to provide increased product developing efficiency and helped customers to shorten the products TTM (time to market) period.
COMPANY QUALITY POLICY
Customer Satisfaction & Continuous Improvement
COMPANY MISSION
Through quality services and innovation, provide our customers with the most trusted and technologically advanced products.
COMPANY VISION
To further our knowledge and skill capabilities as a service provider in the technical fields of forging, stamping and machining.
UKAS/ISO 9001 ACCREDITED PROCEDURES & IN-HOUSE TESTING FACILITY
To ensure compliance with the regulations, we use UKAS/SGS ISO9001 accredited procedures to test our products with in-house testing facility. Yuh Chern is constantly upgrading the latest inspection and testing systems. With the state-of-the-art in-house testing laboratory, we are capable of inspecting diversified products and guaranteeing the reliability, and furthermore boosting customer satisfaction.
Our laboratory is equipped with:
- 30-ton & 200-ton dynamic fatigue testing machines (Chun Yen & Moog Test Controller/CY-6040A & CY-6742)
- 20-ton & 200-ton tensile testing machines (Chun Yen / CY-6042)
- 2.5D image measuring instruments (Carmar / VMM-4030C)
- Reverse 3D scanner (Carl Zeiss / Steinbichler / Comet L3D - 5M)
- Surface roughness tester (Mitutoyo / SJ410)
- 3D coordinate measuring machine (Mitutoyo / CRT-AS574)
- Digital image magnifying detector
- Rockwell Hardness tester (Zwick / ZHR8150LK)
- Magnetic particle tester (Karl Deutsch / K+D 700-ACY)
A tow ball is an attachment that provides a connection between the trailer and the hitch.
Pairing a car or motorcycle trailer with a tow hitch allows you to move your vehicle along with your belongings in one single trip. You can also use these pieces of equipment to tow an out-of-service vehicle to a repair shop or transport a vehicle to a new location when you only have a single driver.
To satisfy the growing demand from the market, we commenced manufacturing of many ball sizes. Our largest truck ball size is 3" for our 10t gooseneck coupling.
To ensure compliance with regulations, we use UKAS/SGS ISO9001 testing facilities & procedures to test our equipment in-house before shipping them to our customers.
| Item NO. | Description | A | B | C | D | E | F | G | H | I | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602210101000 |
1 7/8" × 2000 LB Tow Ball - 3/4" Shank |
Ø47.63 |
3/4"-16 UNF-2A |
44.45 | Ø24.8 | 25 | Ø46 | 6.5 | 44.7 | 109.45 | 2000LB | SAE1045 | Chrome Plating |
| 50221031011 |
1 7/8 inch × 3.5 Ton Tow Ball - 3/4inch Shank |
Ø47.63 |
3/4"-10 UNC-2A |
52.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 124.62 | 3.5 Ton | SAE1045 | Chrome Plating |
| 50221031012 |
1 7/8 inch × 3.5 Ton Tow Ball - 7/8inch Shank |
Ø47.63 |
7/8"-9 UNC-2A |
57.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 129.62 | 3.5 Ton | SAE1045 | Chrome Plating |
| 50221031010 |
1 7/8 inch× 3.5 Ton Tow Ball - 1inch Shank |
Ø47.63 |
1" -8 UNC-2A |
57.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 129.62 | 3.5 Ton | SAE1045 | Chrome Plating |
50MM TOW BALL
| Item NO. | Description | A | B | C | D | E | F | G | H | I | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50221031013 |
1 7/8" × 3.5 Ton Tow Ball - 3/4" Shank |
Ø47.63 |
3/4"-10 UNC-2A |
52.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 124.62 | 3.5 Ton | SAE1045 | Galvanized |
| 50221031014 |
50mm × 3.5 Ton Tow Ball - 7/8" Shank |
Ø50 |
7/8"-9 UNC-2A |
57.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 130.95 | 3.5 Ton | SAE1045 | Chrome Plating |
| 602210201000 |
50mm × 3.5 Ton Tow Ball - 7/8" Shank |
Ø50 |
7/8"-9 UNC-2A |
69.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 142.95 | 3.5 Ton | SAE1045 | Chrome Plating |
| 602210202000 |
50mm × 3.5 Ton Tow Ball - 1" Shank |
Ø49.5 |
1"-14 UNS-2A |
52 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51.83 | 126 | 3.5 Ton | SAE4140 | Chrome Plating |
| 602210301000 |
50mm × 4.5 Ton Tow Ball - 1 1/4" Shank |
Ø50 |
1 1/4"-7 UNC-2A |
70.5 | Ø28.8 | 22 | Ø50.5 | 12.5 | 51 | 143.95 | 4.5 Ton | SAE1045 | Chrome Plating |
50MM FLANGE TOW BALL
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J | K | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602210302000 |
70mm × 4.5 Ton Tow Ball Set - 1 1/4" Shank |
Ø70 |
1 1/4"-12 UNF-2A |
73 | Ø40 | 29.5 | 72 | 26.6 | 95.26 | 200 | 63.38 | 6.35 | 4.5 Ton | SAE4140 | Chrome Plating |
| 602210601000 |
3" × 10 Ton Tow Ball Set - 1 3/4" Shank |
Ø75.8 |
1 3/4"-12 UNF-2A |
88 | Ø46 | 38.2 | Ø92 | 15.5 | 68.36 | 189.1 | 101.6 | 9.51 | 10 Ton | SAE1045 | Chrome Plating |
U-Bolts are mainly used for the connection between the trailer axle and bumper springs. U-bolts are a much easier way to clamp any kind of tubing/round bar.
Our U-Bolt kit includes U-bolts, plates, nuts, and washers, which can be easily assembled onto the trailer axle and the bumper spring.
Galvanized plated hardware resists rust and corrosion and is superior for boat trailers and weather resistance purposes. Furthermore, we use mechanical galvanizing which does not cause hydrogen embrittlement hazard to high-strength steel parts; it's stronger, tougher, and safer.
*Re-tightened after 300 kilometres from installation.
| Item NO. | Description | A | B | C | D | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|
| 502050101003 |
1/2" × 39mm × 4" BSW Round Galvanized U-Bolt |
41.5 | 101.6 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050101004 |
1/2" × 39mm × 4.5" BSW Round Galvanized U-Bolt |
41.5 | 114.3 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050101008 |
1/2" × 39mm × 5" BSW Round Galvanized U-Bolt |
41.5 | 127 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050101005 |
1/2" × 45mm × 5" BSW Round Galvanized U-Bolt |
47.5 | 127 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050101006 |
1/2" × 45mm × 112mm BSW Round Galvanized U-Bolt |
47.5 | 112 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050101007 |
1/2" × 45mm × 6" BSW Round Galvanized U-Bolt |
47.5 | 152.4 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| Item NO. | Description | A | B | C | D | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|
| 502050102002 |
1/2" × 40mm × 4" BSW Square Galvanized U-Bolt |
42.5 | 101.6 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102003 |
1/2" × 40mm × 5" BSW Square Galvanized U-Bolt |
42.5 | 127 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102004 |
1/2" × 40mm × 5.5" BSW Square Galvanized U-Bolt |
42.5 | 139.7 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102005 |
1/2" × 40mm × 6" BSW Square Galvanized U-Bolt |
42.5 | 152.4 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102013 |
1/2" × 45mm × 4" BSW Square Galvanized U-Bolt |
47.5 | 101.6 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102007 |
1/2" × 45mm × 112mm BSW Square Galvanized U-Bolt |
47.5 | 112 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102006 |
1/2" × 45mm × 5" BSW Square Galvanized U-Bolt |
47.5 | 127 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102008 |
1/2" × 45mm × 5.5" BSW Square Galvanized U-Bolt |
47.5 | 139.7 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102009 |
1/2" × 45mm × 6" BSW Square Galvanized U-Bolt |
47.5 | 152.4 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102010 |
1/2" × 50mm × 4" BSW Square Galvanized U-Bolt |
52.5 | 101.6 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102011 |
1/2" × 50mm × 6" BSW Square Galvanized U-Bolt |
52.5 | 152.4 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102012 |
1/2" × 80mm × 120mm BSW Square Galvanized U-Bolt |
80 | 120 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102014 |
1/2" × 50mm × 3" BSW Square Galvanized U-Bolt |
52.5 | 76.2 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102015 |
1/2" × 50mm × 5" BSW Square Galvanized U-Bolt |
52.5 | 127 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102016 |
1/2" × 50mm × 7" BSW Square Galvanized U-Bolt |
52.5 | 177.8 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| 502050102017 |
1/2" × 56mm × 5.5" BSW Square Galvanized U-Bolt |
56 | 139.7 | 65 | 1/2"-13UNC-1A | 4616 kgf | SS400 | Mechanical Galvanized |
| Item NO. | Description | A | B | C | D | E | F | G | H | 4-I |
|---|---|---|---|---|---|---|---|---|---|---|
| 502050102000 |
5/8" × 45mm × 165mm Square Galvanized Plate U-Bolt Kit |
47.5 | 165.1 | 75 | 5/8"-11-UNC-2A | □110 | 72.6 | Ø20 | 58.3 | 18 |
| J | K | L | M | N | Capacity | Material | Surface Finish | |||
| 10 | 40 | 60 | Ø16.8 | 10 | 7702 kgf | SS400 | Mechanical Galvanized | |||
| Item NO. | Description | A | B | C | D | E | F | G | H | 4-I |
|---|---|---|---|---|---|---|---|---|---|---|
| 502050102001 |
5/8" × 50mm × 177mm Square Galvanized Plate U-Bolt Kit |
51.5 | 177.8 | 75 | 5/8"-11-UNC-2A | □110 | 72.6 | Ø20 | 58.3 | 18 |
| J | K | L | M | N | Capacity | Material | Surface Finish | |||
| 10 | 40 | 60 | Ø16.8 | 10 | 7702 kgf | SS400 | Mechanical Galvanized | |||
| Item NO. | Description | A | B | C | D | E | F | G | H | 4-I |
|---|---|---|---|---|---|---|---|---|---|---|
| 502050101001 |
5/8" × 45mm × 165mm Round Galvanized Plated U-Bolt Kit |
47.5 | 165.1 | 75 | 5/8"-11-UNC-2A | □110 | 72.6 | Ø20 | 58.3 | 18 |
| J | K | L | M | N | Capacity | Material | Surface Finish | |||
| 10 | 40 | 60 | Ø16.8 | 10 | 7702 kgf | SS400 | Mechanical Galvanized | |||
| Item NO. | Description | A | B | C | D | E | F | G | H | 4-I |
|---|---|---|---|---|---|---|---|---|---|---|
| 502050101002 |
5/8" × 50mm × 165mm Round Galvanized Plated U-Bolt Kit |
52.5 | 165.1 | 75 | 5/8"-11-UNC-2A | □110 | 72.6 | Ø20 | 58.3 | 18 |
| J | K | L | M | N | Capacity | Material | Surface Finish | |||
| 10 | 40 | 60 | Ø16.8 | 10 | 7702 kgf | SS400 | Mechanical Galvanized | |||
| Item NO. | Description | A | B | C | D | E | F | G | H | 4-I |
|---|---|---|---|---|---|---|---|---|---|---|
| 502050101000 |
5/8" × 60mm × 190mm Round Galvanized Plate U-Bolt Kit |
62.5 | 190.5 | 75 | 5/8"-11-UNC-2A | □110 | 78 | Ø18 | 72 | 17 |
| J | K | L | M | N | Capacity | Material | Surface Finish | |||
| 10 | 40 | 60 | Ø16.8 | 10 | 7702 kgf | SS400 | Mechanical Galvanized | |||
Dust covers and wheel bearing protectors help to keep dust and dirt out of the wheel, to ensure that the trailer wheel axle is clean & lubricated, and to promote smooth, safe towing of your trailer. The wheel bearing protector automatically maintains internal pressure to avoid seal damage and continuously lubricates the axle center to avoid jamming.
Your trailer's wheel axle needs to be lubricated to dissipate heat, stave off corrosion, and keep those wheels a-rolling. There are a few general types of wheel-bearing lubrication systems, each with its particular maintenance characteristics.
| Item NO. | Description | A | B | C | D | E | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|
| 503500501005 | 1.781" Dust Cover | 6.5 | 3.1 | 30.5 | Ø45.4 | 48.9 | Fe | Chrome Plating |
| 503500501006 | 2.44" Dust Cover | 7 | 3.7 | 38.6 | Ø63.5 | 67.1 | Fe | Chrome Plating |
| Item NO. | Description | A | B | C | D | E | F | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|
| 503500501003 | 1.781" Dust Cover (Rubber Plug) | Ø47 | Ø45.4 | 6.5 | 30.5 | 3.1 | Ø25 | Fe | Chrome Plating |
| 503500501004 | 2.44" Dust Cover (Rubber Plug) | Ø66 | Ø63.6 | 7.8 | 40.8 | 4.6 | Ø30 | Fe | Chrome Plating |
| Item NO. | Description | A | B | C | D | Material | Surface Finish |
|---|---|---|---|---|---|---|---|
| 50350050001 | 1.781" Wheel Bearing Protector | 50.8 | 7.5 | Ø45.3 | Ø47.6 | Fe | Chrome Plating |
| 50350050002 | 1.98" Wheel Bearing Protector | 50.8 | 9.5 | Ø50.3 | Ø50.8 | Fe | Chrome Plating |
| 503500501000 | 2.44" Wheel Bearing Protector | 50.9 | 9.5 | Ø61.97 | Ø63.4 | Fe | Chrome Plating |
Coupling is primarily used on the trailer to perform the enormous task of pulling a variety of heavy loads at highway speeds.
Trailer couplings come in standard sizes, and many can be adjusted for a more secure connection. Our range of trailer couplings is engineered to meet the highest specifications to ensure reliable attachment for trailers of varying weights and load sizes.
3inch FIXED RING COUPLING - 6,000KG
70MM BALL ELECTRIC COUPLING W/PARK LEVER 4.5T
10 TON GOOSE NECK COUPLING
A pintle hitch is a tow hitch that uses a tow ring or coupling configuration to secure a hook or a ball combination to tow an unpowered vehicle. Pintle hooks give you a reliable connection for your heavy-duty trailer. Our pintle hook kits include ball mount style hitches and jawed pintle mounts which offer excellent flexibility of movement. Furthermore, we provide options for a combination of receiver bar, pintle hook, and a tow ball, for towing multiple types of trailers, providing further versatility.
Features :
* Black powder-coated finish. * Drop forged carbon steel & alloy steel structure.
* Replaceable hitch ball. * Spring-loaded latch with safety chain and pin.
3.5 T BALL - 6 TON COMBINATION BALL AND PINTLE HOOK
| Item NO. | Description | A | B | C | 4-D | E | F | G | H | I | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220401001 |
5 Ton Pintle Hook + 4 X HT Bolts & Nuts |
112.5 | 85 | 45 | Ø13.5 | 50 | 49 | 153 | 85 | 129.31 | 5 Ton | SAE1045 | Liquid Coating |
| 602220601000 |
10 Ton Pintle Hook + 4HT Bolts & Nuts |
112.5 | 85 | 45 | Ø13.5 | 50 | 49 | 153 | 85 | 129.31 | 10 Ton | SAE1045 | Liquid Coating |
| 602220601001 |
14.5 Ton Pintle Hook + 4 HT Bolts & Nuts CRN 45954 D value 73kN |
112.5 | 85 | 45 | Ø13.5 | 50.5 | 53 | 162 | 85 | 146.97 | 14.5 Ton | SAE1045 | Liquid Coating |
| 602220801000 |
20 Ton Pintle Hook + 4HT Bolts & Nuts |
112.5 | 85 | 45 | Ø13.5 | 50.5 | 53 | 162 | 85 | 146.97 | 20 Ton | SAE1045 | Liquid Coating |
50MM 6 TON X 2INCH ONE PIECE COMBINATION PINTLE HOOK
5 TON PINTLE HOOK WITH 2INCH RECEIVER BAR - ONE PIECE
50MM QUICK RELEASE COMBINATION PINTLE HOOK
70MM QUICK RELEASE PINTLE HOOK
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J | K | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220401005 | UN45000 | 56 | Ø10.5 | 129.3 | 83 | 137.21 | 52.58 | Ø42 | 94.27 | 47.54 | 40.5 | 94.8 | 3500kg | SAE1045 | Liquid Coating |
| 602220401004 | UN45100 | - | 17 | 129.3 | 90 | 137.21 | 52.58 | Ø42 | 94.27 | 47.54 | 12.5 | 94.8 | 3500kg | SAE1045 | Liquid Coating |
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220401007 |
PCDE070 Pintle Hook Combination 50mm Tow ball |
56 | Ø10.5 | 123 | 83 | 133.55 | 15 | 192.81 | Ø50 | 58 | Ø42 |
| K | L | M | N | O | Capacity | Material | Surface Finish | ||||
| 131 | 83.5 | 45 | 35.96 | 91 | 3500kg | SAE1045 | Liquid Coating | ||||
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220401006 |
PCDE071 Pintle Hook Combination 50mm Tow ball |
- | 17 | 123 | 90 | 133.55 | 15 | 192.81 | Ø50 | 58 | Ø42 |
| K | L | M | N | O | Capacity | Material | Surface Finish | ||||
| 131 | 83.5 | 45 | 8 | 91 | 3500kg | SAE1045 | Liquid Coating | ||||
Using our tow bar adaptor eliminates the need to buy a base plate or a tow bar.
The Pintle Hook Adaptor can be used to convert your tow bar configuration, from a ring coupling trailer to a pintle hitch heavy-duty receiver-style tow bar.
Features:
* Steel with a black liquid-coat finish for long-lasting durability
* Continuous strong welded support bracket carbon steel construction
PINTLE TOW BAR ADAPTOR 1 1/4" HOLE + 7/8" BUSH
2" RECEIVER BAR - 8 HOLES
The receiver mount can take the form of a tow ball to allow swiveling and articulation of a trailer, or a tow pin, or a tow hook with a trailer loop. It is one of the most common methods to mount a pintle hook.
The receiver bar is designed according to the height between the vehicle tail and the trailer front. The receiver bar end is connected to the trailer hitches, which will set the tow ball locked on the other end of the receiver bar. This is a standard trailer setup.
Whether you’re taking your new boat to the lake for a summertime spin or towing your camper into the mountains, you’ll need a tow hitch (also called a trailer hitch) attached to your vehicle.
2" RECEIVER MOUNT HOLLOW + 50MM × 3500KG TOW BALL
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602260201001 |
2" Receiver Mount Cast Suit 1 1/4" Tow Ball 2" Drop |
2" | 225mm | 76 | Ø32 | 372 | 25.5 | 177.19 | Ø16.5 | 92.5 | □50 | 4.5T | SAE1045 | Powder Coating |
| 602260201000 |
2" Receiver Mount Cast Suit 1 1/4" Tow Ball - 4" Drop |
4" | 240mm | 76 | Ø32 | 372 | 25.5 | 177.19 | Ø16.5 | 92.5 | □50 | 4.5T | SAE1045 | Powder Coating |
The safety chain anchor plate is a safety device connected from the trailer equipment to the trailer. The safety chain anchor plate is an indispensable part to ensure that the trailer is properly connected to the trailer. To ensure that in the event of a tow ball or coupling failure, you can still safely guide the trailer and maintain control, so that you can stop the vehicle stably and avoid dangerous situations. Two safety chains are required and must be connected to their own chain holder. The safety chain anchor plate is just one small detail. If used incorrectly, it may cause major problems. Of course, the safety chain anchor plate increases the safety and responsibility of driving. Ensuring that the function of the safety chain anchor plate is effective and connected is the first step of road safety.
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J | K | Capacity | Material | Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220501000 |
10mm Safety Chain Anchor Plate |
11.5 | 35.5 | 65.5 | Ø13 | 29.65 | 42.15 | 50.2 | R65 | 1 | 35 | 5 | 8 ton | SAE1045 | Electro-Plating (Black) |
| 602220601003 |
13mm Safety Chain Anchor Plate |
15.5 | 47 | 69 | Ø16 | 30 | 45 | 61 | R45.5 | 1.4 | 24.5 | 6 | 13.5 ton | SAE1045 | Electro-Plating (Black) |
| 602220801001 |
16mm Safety Chain Anchor Plate |
19 | 58 | 79 | Ø19 | 37 | 55 | 86 | R95 | 5.5 | 45 | 6 | 22 ton | SAE1045 | Electro-Plating (Black) |
| 602220901000 |
19mm Safety Chain Anchor Plate |
21.5 | 72 | 95.5 | Ø22 | 41.5 | 64 | 105 | R95 | 5.5 | 45 | 6 | 30 ton | SAE1045 | Electro-Plating (Black) |
| Item NO. | Description | A | B | C | D | E | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|
| 50610010052 | 3" Drop Axle Assembly - 45SQ / 45RD | 76.2 | □48 | Ø48 | 187 | 31.5 | 19798 kgf | SS400 | Anti-Rust Oil |
| 50610010053 | 4" Drop Axle Assembly - 45SQ / 45RD | 101.6 | □47.5 | Ø47.5 | 187 | 31.5 | 23882 kgf | SS400 | Anti-Rust Oil |
| 50610010018 | 4" Drop Axle Assembly - 50SQ / 45RD | 101.6 | □53 | Ø48 | 187 | 31.5 | 20161 kgf | SS400 | Anti-Rust Oil |
| 50610010054 | 4" Drop Axle Assembly - 50SQ / 50RD | 101.6 | □53 | Ø53 | 187 | 31.5 | 20500 kgf | SS400 | Anti-Rust Oil |
Securing your trailers is important!
We supply a wide selection of locking solutions to keep your trailers safe and secure.
DUAL TRAILER SAFETY LOCK + PADLOCK
SMALL TRAILER + PADLOCK
TREGG PIN + LOCK
| Item NO. | Description | A | B | C | D | E | Material | Finish |
|---|---|---|---|---|---|---|---|---|
| 602340501002 | 5/8" Receiver Bar Lock 65mm (Square) | Ø15.8 | 65 | 31.3 | 45 | 51.3 | Fe | Chrome Plating |
| 602340501000 | 5/8" Receiver Bar Lock 85mm (Square) | Ø15.8 | 85 | 31.3 | 45 | 51.3 | Fe | Chrome Plating |
| 602330401000 | 1/2" Receiver Bar Lock 85mm (Square) | Ø12.7 | 85 | 31.3 | 45 | 51.3 | Fe | Chrome Plating |
| 602330401001 | 1/2" Receiver Bar Lock 65mm (Square) | Ø12.7 | 65 | 31.3 | 45 | 51.3 | Fe | Chrome Plating |
| Item NO. | Description | A | B | C | Material | Finish |
|---|---|---|---|---|---|---|
| 602340501001 | 5/8" Receiver Bar Lock 65mm (Straight) | Ø15.8 | 71 | 150 | Fe | Chrome Plating |
| 602340401000 | 1/2" Receiver Bar Lock 65mm (Straight) | Ø12.7 | 71 | 150 | Fe | Chrome Plating |
| 602340401001 | 1/2" Receiver Bar Lock 85mm (Straight) | Ø12.7 | 91 | 150 | Fe | Chrome Plating |
| Item NO. | Description | A | B | C | D | E | F | G | H | Material | Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 602320501000 | 5/8" Receiver Bar Pin + Clip - 2 Hole | Ø15.8 | 95 | 30 | 2-Ø5 | 12 | 24 | Ø4 | 75.6 | SAE1015 | White Zinc Galvanized |
| 602310401000 | 1/2" Receiver Bar Pin + Clip | Ø12.7 | 83 | 33 | Ø3.5 | 7 | - | Ø2 | 41 | Fe | White Zinc Galvanized |
5/8" RECEIVER BAR LOCK (SILENT TYPE)
3/8" LEVER COUPLING LOCKING PIN
Spring
Spring Pin
(not assembly)
LEVER COUPLING LOCK PIN KIT
AXLE ELECTRIC WELD RING
Our Axle Weld Rings are available in two major types: square-shaped and round-shaped. The square-shaped weld ring features a round hole at the center and four-bolt holes near each corner. Our round-shaped weld rings have two options: square center hole and round center hole. Both are surrounded by five smaller holes near the edge.
45MM SQUARE WELD RING
50MM SQUARE WELD RING
60MM ROUD WELD RING
Our excellence in product development has seen our production capabilities diversify into various fields including the Transportation Industry.
We have developed numerous after-market Motor Vehicle spare parts, Trailer parts, and other parts within the transportation industry that require the highest level of quality and satisfy stringent safety standards.
ALUMINUM EASY JACK
TRAILER LOCK AND GUIDE (AUS TYPE)
2T MARINE COLLAR
| Item NO. | Description | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | Capacity | Material | Surface Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 602220201001 |
Trailer Ring Coupling GM 10300A |
155 | 120 | Ø15 | Ø10 | Ø34.2 | 90 | 55 | Ø8.4 | Ø20 | 102 | 70 | 15 | 181.2 | 93.5 | 45.5 | 25000 kg | SAE1541 | Powder Coating |
| 602220301000 |
Trailer Ring Coupling GM 10400A |
180 | 140 | Ø17 | Ø10 | Ø34.2 | 120 | 80 | Ø8.4 | Ø20 | 110 | 70 | 20 | 181.2 | 93.4 | 40.6 | 35000 kg | SAE1541 | Powder Coating |
| 602220401003 |
Trailer Ring Coupling GM 10500A |
200 | 160 | Ø21 | Ø10 | Ø34.2 | 140 | 100 | Ø8.4 | Ø20 | 110 | 70 | 19 | 181.2 | 94.5 | 41.4 | 50000 kg | SAE1541 | Powder Coating |
